MS328
MS HD Power 13A UK Mains Plugs.
Available in 4 different platings Polished Copper, Silver, Gold, Rhodium and all with every contact surface plated in the chosen finish.
Patented UK 3 pin mains plug securing up to 16mm diameter cables and up to 4mm power and earth conductors internally.
High quality 13A UK 3 pin plug has been designed to be used with audio equipment power cables for the best power transmission with no compromises. All the electrical parts (polished pins and all internal parts) are made from premium quality copper, the Fuse Clips are made of high spring rate Phosphor Bronze and with Silver, Gold, Rhodium Plating – and supplied fitted with a high quality 13A silver plated fuse.
The patented design allows for easy cable fitting (instructions provided) and the ease of cable fitting cannot be under estimated, some other brands are difficult to wire up with thicker cables.
The plug casing is manufactured from nylon material, offering durability, high insulation, light weight and good looks.
The heavy duty mains wire-clamps design ensure an air tight connection to ensure perfect power transmission and also protect the power cable wires from damage over time – inferior plugs secure the cables by the grub screws twisting down onto the cable directly and can be prone to material ‘creep’ over time, causing damage.
FEATURES
Complied with BS-1363 safely standards.
Capable of fitting up to 4mm²(AWG #10) core conductors securely.
Capable of fitting up to 16mm diameter power cables.
Heavy gauge wire-clamps improve power transmission and protect electric-wire damage from fixing screws.
Fuse clips made of high spring rate phosphor bronze and either plated or polished depending on version
Comes with 13A silver fuse.
High-insulation, durable thermoplastic housing.
VERSIONS
Copper: Polished plug pins to improve conductivity.
Silver: 1.0µm pure 925-silver plating on all plug pins, wire-clamps and fuse clips.
Gold: 3.0µm 24K gold plating on all plug pins, wire-clamps and fuse clips.
Rhodium: 1.0µm rhodium plating on all plug pins, wire-clamps and fuse clips.
SPECIFICATIONS
Type of Plug: BS-1363, un-switched
Fuse Adopted: BS-1362
Mains Voltage: 200~240 VAC Max. Current:13 Amp.
Dimensions: 54mmW x 68mmL x 35mmH (Housing Only)
Net Weight: 100g (net)
Analogue Seduction (Peterborough)
